• Meets current standards for 3A and ASME BPE-2009
• Ranges from 1,000 psi to 15,000 psi
• Process temperatures up to 300°F for use in more applications
• 4 inch size with 1-1/8 inch flanged process connection
• Electropolished 304 Stainless steel case with welded 316L Stainless steel socket and process connection for greater performance in high pressure applications
• 316L Stainless steel wetted materials electropolished to Ra25 or better
• Scratch-resistant laminated safety glass provides clear viewing without discoloring
• Optional liquid filling lubricates gauge internals and extends service life by dampening the effects of vibration, pulsation and shock
• C.I.P, S.I.P and Autoclave* for the demanding needs of the sanitary market

*Only dry case gauges are recommended for Autoclave

• High pressure applications in:

  • Dairy
  • Food
  • Chemical
  • Biotechnology
  • Pharmaceutical
