Home > Dial Indicating Pressure Gauges > 900 Series ABS & Stainless Steel Liquid Filled Gauges
3 YEAR WARRANTY
Printable Catalog Page
900 Series ABS & Stainless Steel Liquid Filled Gauges
|
|
|
|
Product Specifications Gauge Dimensions Accuracy/Standard Dial Configuration Diaphragm Seals Options & Accessories Technical Manual Reference Information Standard Item Part Numbers
|
Features & Benefits
- Extremely high quality pressure gauges, liquid filled for extended service life and shock resistance
- Ranges available from vacuum to 15,000 psi
- 1-1/2, 2, 2-1/2, 4 inch sizes – bottom or back connected
- Lightweight shatter-resistant ABS case with Plexiglass™ lens for extra strength, or 304 Stainless steel case with Polycarbonate lens.
- Unique o-ring case and connection seals guard against leakage and protect against shock and vibration
- Relief disc on top or back provides positive case relief
- Brass and copper alloy movement
- High grade Glycerine fill dampens the effects of pulsation, vibration and shock loads, and provides lubrication of the movement
- Volume oriented
- Stock availability
Applications
- Industrial applications where pulsation, vibration and shock are present
Operating Specifications
- Working Pressure Limitations
- Dynamic Pressure
The working pressure should be limited to 60% of the dial range - Static Pressure
The working pressure, when no sharp fluctuations occur, should be limited to 90% of the dial range.
- Dynamic Pressure
- Ambient Temperature
-4°F to 140°F (-20°C to 60°C) Glycerine Fill
-40°F to 140°F (-40°C to 60°C) Special Fill - Media Temperature
-4°F to 140°F (-20°C to 60°C) Glycerine Fill
-40°F to 140°F (-40°C to 60°C) Special Fill
