100 Series Mini, Hard Seat Needle Valves

REQUEST A QUOTE
Application Brochures
Oil & Gas
  • Compact size valve built for maximum durability and robust performance in the toughest applications
  • 100% helium leak tested to 1 x 10-4 ml/s for guaranteed performance and reliability
  • Hard seat valves have a maximum pressure of 10,000 psi for Stainless Steel and Steel models; 6,000 psi for Brass
  • Available in Zinc-nickel plated Steel, electropolished Stainless Steel and Brass
  • FKM o-ring seal and PTFE back-up ring below the stem threads to protect from corrosion and galling; PTFE or Graphite packing optional
  • All stems are 316 Stainless Steel
  • All stem threads are rolled for strength and ease of operation
  • Patented body-to-bonnet, metal-to-metal seal is designed to significantly increase the pressure range of the valve (U.S. Patent 7,758,014)

If you are viewing on a smaller screen or with screen zoom, please use the horizontal scroll bar at the bottom of this table to see all information.

ORDERING INFORMATION

SERIES 1 100 Series, hard seat
CONNECTION SIZES 01 1/8" NPT 42 7/16"-20 UNF-2B*
02 1/4" NPT 43 9/16"-18 UNF-2B*
VALVE TYPES MMB Male-Male, Brass EMFC Extended Male-Female, Steel EMFS Extended Male-Female, Stainless Steel
MFB Male-Female, Brass MFC Male-Female, Steel MFS Male-Female, Stainless Steel
EFFB Extended Female-Female, Brass EFFC Extended Female-Female, Steel EFFS Extended Female-Female, Stainless Steel
FFB Female-Female, Brass FFC Female-Female, Steel FFS Female-Female, Stainless Steel
MMAB Male-Male Angle, Brass MMAC Male-Male Angle, Steel MMAS Male-Male Angle, Stainless Steel
MFAB Male-Female Angle, Brass MFAC Male-Female Angle, Steel MFAS Male-Female Angle, Stainless Steel
FFAB Female-Female Angle, Brass FFAC Female-Female Angle, Steel FFAS Female-Female Angle, Stainless Steel
MMC Male-Male, Steel MMS Male-Male, Stainless Steel

* Available only on EFFB, EFFC, and EFFS valve types.

ORDERING INFORMATION - Additional Options

PACKINGS * P1 PTFE P2 Graphite
STEM TIPS T1 Non-rotating (316 stainless standard) T6 Ball (carbide) T8 Ball (Monel)
T5 Ball (440C stainless) T7 Ball (ceramic) T9 Non-rotating regulating (316 Stainless)
O-RINGS ** EM1 EPDM KZ1 FFKM (Kalrez® 3018 or equivalent) NB1 NBR
PANEL MOUNTINGS PM1 Panel mount (1 nut) PM2 Panel mount (2 nuts)
HANDLES HL2 2-1/2" "T" HL4 1-3/8" Phenolic
HL3 1" Round knurled HL5 1-3/4" Phenolic

* If a packing option is chosen, maximum pressure rating is 6,000 psi. Refer to the "Pressure vs Temperature: Packing Style with Compatible Fluid" chart.
** Other o-ring materials available on request.

Please note that the standard o-ring in all the NOSHOK mini valves is FKM and the standard handles are brass round knurled (HL3) handles, steel mini "T" handles (HL1), and 316SS mini "T" handles (HL1).

The handle material will always match the material of the valve, unless otherwise specified. For example, the round knurled (HL3) on a 102-FFB will be brass. When only the standard configuration is needed, no additional designations are necessary. Please consult the factory for special application requests.

To meet all of your specific application requirements, the following additional options are available for these needle valves. To order all or any of these options, simply add them to the part number as shown in the diagram below.

NOTE 1: The example shown includes ALL possible additional options. Please include ONLY the options required for your application when building your part number. (EXAMPLE: 102-MFC-HL3)

NOTE 2: When a packing option is selected, an o-ring option is NOT available.

If you are viewing on a smaller screen or with screen zoom, please use the horizontal scroll bar at the bottom of this table to see all information.

SPECIFICATIONS
Materials Zinc-nickel plated steel, electropolished 316 Stainless Steel, 360 Brass
Connections 1/8" NPT, 1/4" NPT, 7/16"-20 UNF-2B, 9/16"-18 UNF-2B Male-male, Male-female, Female-female, in-line and angled configurations
Pressure ratings* Brass: 6,000 psi @ 200 °F
Steel: 10,000 psi @ 200 °F
Stainless Steel: 10,000 psi @ 200 °F
Orifice size 0.172"
Flow coefficient CV 0.42
Stem seal & type All 316 Stainless Steel stems with FKM o-ring and PTFE back-up ring below the threads, PTFE or Graphite packing optional
Options Panel mountings, o-ring materials, handles, packings, regulating stem and stem tips
Weight Approximately 0.5 lb.

* If a packing option is chosen, maximum pressure rating is 6,000 psi. Refer to the "Pressure vs Temperature: Packing Style with Compatible Fluid" chart.

All NOSHOK valve products conform to the MSS SP-99 instrument valves standards, and valves supplied with packing also conform to MSS SP-132 compression packing systems for instrument valves standard.

Options & Accessories

  • Packing*
    • PTFE (P1)
    • Graphite (P2)
  • Stem Tips
    • Non-rotating (316 Stainless Steel) (T1)
    • Ball, 440C Stainless Steel (T5)
    • Ball, carbide (T6)
    • Ball, ceramic (T7)
    • Ball, Monel (T8)
    • Non-rotating regulating, 316 Stainless Steel (T9)
  • O-Rings (Other o-ring materials available on request)
    • EPDM (EM1)
    • FFKM, Kalrez® 3018 or equivalent (KZ1)
    • NBR (NB1)
  • Panel Mount
    • 1 nut (PM1)
    • 2 nuts (PM2)
  • Handles
  • Cleaning For Oxygen Service (Stainless Steel & Brass Only)

* If a packing option is chosen, maximum pressure rating is 6,000 psi. Refer to the Pressure vs. Temperature: Packing Style with Compatible Fluid chart

Note: The standard o-ring in all the NOSHOK mini valves is FKM and the standard handles are Brass round knurled (HL3) handles, Steel mini “T” handles (HL1), and 316SS mini “T” handles (HL1). The handle material will always match the material of the valve, unless otherwise specified. For example, the round knurled (HL3) on a 102-FFB will be Brass.

When only the standard configuration is needed, no additional designations are necessary. Please consult the factory for special application requests.

NOSHOK offers multiple assembly options to meet your specific system requirements. Consult factory to discuss your customized solution.

For NOSHOK Mini Valves with Brass & Steel valve types:

WARNING: This product can expose you to chemicals including Lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov


For NOSHOK Mini Valves with Stainless Steel valve types:

WARNING: This product can expose you to chemicals including Nickel, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
