5030/5130 Series 5-Valve Natural Gas Manifold Valves, Hard Seat & Soft Seat/Tip

REQUEST A QUOTE VIEW BY PART NUMBER
Download Literature
Water/
Wastewater
Oil & Gas

Custom Valve Solutions for the Oil and Gas Industry | Oil and Gas Measurement & Instrumentation

SV Series Stabilized Connector

Legacy Product: NOSHOK SV Series Connectors Instructions

  • Designed for use with differential pressure transmitters incorporating two isolation valves, two equalizing valves and a vent valve required in natural gas applications
  • Flare Pattern™ valve configuration provides maximum clearance for fingers during operation
  • Soft tip valves feature a patented Acetal non-rotating soft tip stem, and a back-up metal-to-metal seal (U.S. Patent 6,820,857)
  • Available in block, single flange, or double flange connection for remote or direct installation
  • 100% helium leak tested to 1 x 10-4 ml/s for guaranteed performance and reliability
  • 5030 Series hard seat valves have 10,000 psi pressure rating @ 200 °F
  • 5130 Series soft seat/tip valves have 6,000 psi pressure rating @ 200 °F
  • 5130 Series valves also feature a replaceable Acetal seat, and straight through porting for bidirectional, high capacity flow and easy roddable cleaning on the block valves
  • Blow-out proof stem provides a secondary stem seal in the full open position
  • FKM o-ring seal and PTFE back-up ring below the stem threads to protect from corrosion and galling; PTFE or Graphite packing optional
  • All stems are 316 Stainless Steel
  • All stem threads are rolled for strength and ease of operation
  • One-piece bonnet with a metal-to-metal seal to the valve body below the bonnet threads
  • Slotted spring pin to prevent accidental loosening
  • Vinyl dust caps for bonnets and stems (non-packing)
  • Patented body-to-bonnet, metal-to-metal seal is designed to significantly increase the pressure range of the valve (U.S. Patent 7,758,014)

If you are viewing on a smaller screen or with screen zoom, please use the horizontal scroll bar at the bottom of this table to see all information.

ORDERING INFORMATION

SERIES 5 5-valve
SEATS 0 Hard seat 1 Soft seat/tip
PROCESS TYPE 3 Natural gas flow
CONNECTION 0 1/2" NPT or flange
VALVE TYPES MFC Flange-Female, Steel MFS Flange-Female, Stainless Steel MMC Flange-Flange, Steel
FFC Female-Female, Steel FFS Female-Female, Stainless Steel MMS Flange-Flange, Stainless Steel

To meet all of your specific application requirements, the following additional options are available for these manifold valves. To order all or any of these options, simply add them to the part number as shown in the diagram below.
NOTE 1: The example shown includes ALL possible additional options. Please include ONLY the options required for your application when building your part number. (EXAMPLE: 5130-MFC-P1)
NOTE 2: When a packing option is selected, an o-ring option is NOT available.
NOTE 3: The standard o-ring in all the NOSHOK manifold valves is FKM and T1 hard non-rotating (316SS standard) stem tip is the only option
available for the Isolation valves on the 5130 Series. All other stem tip options are available for the equalize and vent valves.

ORDERING INFORMATION - Additional Options

BODY CONFIGURATION FP Flare Pattern™
SOFT SEATS PK1 PEEK KF1 PCTFE
PACKINGS† P1 PTFE P2 Graphite **
STEM TIPS T1 Non-rotating (316 stainless)** T4 PEEK*** T7 Ball (ceramic)** T10 Regulating Acetal***
T2 Acetal*** T5 Ball (440C stainless)** T8 Ball (Monel)** T11 Regulating PTCFE***
T3 PTCFE*** T6 Ball (carbide)** T9 Non-rotating regulating (316 Stainless)** T12 Regulating PEEK***
O-RINGS* EM1 EPDM KZ1 FFKM (Perfluoroelastomer) NB1 NBR
HANDLES HL1 1-13/16" Mini "T" HL4 1-3/8" Phenolic
HL3 1" Round knurled HL5 1-3/4" Phenolic

† If a packing option is chosen, maximum pressure rating is 6,000 psi. Refer to the "Pressure vs Temperature: Packing Style with Compatible Fluid" chart.
* Other o-ring materials available on request.
** For 5030 only.
*** For 5130 only.

Please note that the standard o-ring in all the NOSHOK valves is FKM and the standard handles are isolation “T” handles (HL2) and equalizing & vent 1-3/8" mini “T” handles (HL7).

The handle material will always match the material of the valve, unless otherwise specified. For example, handles on the 5130-MFC will be steel. When only the standard configuration is needed, no additional designations are necessary. Please consult the factory for special application requests.

To meet all of your specific application requirements, the following additional options are available for these manifold valves. To order all or any of these options, simply add them to the part number as shown in the diagram below.

NOTE 1: The example shown includes ALL possible additional options. Please include ONLY the options required for your application when building your part number. (EXAMPLE: 5130-MFC-P1)

NOTE 2: When a packing option is selected, an o-ring option is NOT available.

NOTE 3: The standard o-ring in all the NOSHOK manifold valves is FKM and T1 hard non-rotating (316SS standard) stem tip is the only option available for the Isolation valves on the 5130 Series. All other stem tip options are available for the equalize and vent valves.

If you are viewing on a smaller screen or with screen zoom, please use the horizontal scroll bar at the bottom of this table to see all information.

SPECIFICATIONS
Materials Zinc-nickel plated carbon steel, electropolished 316 Stainless Steel
Connections Flange-Flange
1/2" NPT-Flange
1/2" NPT-1/2" NPT
Pressure ratings* Hard Seat: 10,000 psi @ 200 °F
Soft Seat: 6,000 psi @ 200 °F
Orifice size 0.187"
Flow coefficient Hard Seat: CV 0.44
Soft Seat/tip: CV 0.76
Steam seal & type All 316 Stainless Steel stems with FKM o-ring and PTFE back-up ring below the threads.
Additional features Two static (test) ports, color coded vinyl bonnet and stem dust cap, patented soft seat/tip stem design on equalizing and vent valves
Options Panel mountings, o-ring materials, handles, packings, regulating stem and stem tips
Weight Approximately 4.2 lb. without flange
Approximately 6.0 lb. with flange

* If a packing option is chosen, maximum pressure rating is 6,000 psi. Refer to the "Pressure vs Temperature: Packing Style with Compatible Fluid" chart.

All NOSHOK valve products conform to the MSS SP-99 instrument valves standards, and valves supplied with packing also conform to MSS SP-132 compression packing systems for instrument valves standard.

Dimensions Download Data Sheet Flow Schematic Frequently Asked Questions Reference Information Trademark Information Warranty Information

Options & Accessories

Installed Options & Accessories

  • Packing
  • PTFE Manifold Gasket Ring (RG1-TF1)
  • Graphite Manifold Gasket (RG1-GF1)
  • Traditional to Coplanar Flange Adaptor (TCA-S)

Connectors

  • NOSHOK offers non-stabilized and stabilized Connectors, with or without an integral block valve
  • These connectors are designed to reinforce the entire installation by shifting radial-stress load away from the NPT connections
  • Mounted onto the orifice flange or the orifice fitting, connectors are sometimes referred to as a “Root Valve” or primary isolation valve

View NOSHOK Connectors

Dielectric Kits DK Series

Dielectric Kits are designed to maintain the integrity and reliability of the pipeline and piping system through safety and corrosion protection. Dielectric Kits provide a non-conductive barrier between the process piping and the instrument and isolate components from the effects of electrical current. By eliminating metal-to-metal contact, current is halted to prevent corrosion and aid in the cathodic protection of the system.

  • One Piece Dielectric Gasket, Pair, Steel, Acetal (DK1)
  • One Piece Dielectric Gasket, Pair with Stainless Steel Bolts, Stainless Steel, Acetal (DK1-SS)
  • PTFE Gasket with Dielectric Shim, Pair, Steel, PTFE, PVC (DK2)

DK1

  • Single piece design combining a Acetal sealing gasket and Acetal dielectric shim
  • Bolts, washers and dielectric bushings are included with the kits
  • Cannot be used in conjunction with seal rings or o-rings
  • Seal rings or o-rings not required

DK2

  • Used as an alternative to a one-piece design when a separate sealing gasket or o-ring is required
  • Two piece design consisting of a PTFE sealing gasket and PVC dielectric shim
  • Bolts, washers and dielectric bushings are included with the kits

Specifications:

  • Material: Acetal, PVC
  • Max operating temp 150 °F
  • Dielectric strength exceeds 1/32 air arc gap approximately 2,500 Vdc

All 316SS products meet the requirements of NACE MR0175/ISO 15156-3.

WARNING: This product can expose you to chemicals including Lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

WARNING: This product can expose you to chemicals including Nickel, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Differential Pressure to Differential Pressure Adaptor

NOSHOK Differential Pressure to Differential Pressure Adaptors allow two differential pressure transmitters to be mounted on a single set of orifice taps. This configuration is ideal for applications such as bi-directional flow, and custody transfer where only a single set of orifice taps is available. Multiple adaptors are available for various application configurations and space restrictions.

  • ΔP to ΔP Adaptor - 3/8” Bore, 23” Length, Steel (DP1-DP1-CS)
  • ΔP to ΔP Adaptor - 3/8” Bore, 23” Length, Stainless Steel (DP1-DP1-SS)
  • ΔP to ΔP Adaptor - 3/8” Bore, 9” Length, Steel (DP2-DP2-CS)
  • ΔP to ΔP Adaptor - 3/8” Bore, 9” Length, Stainless Steel (DP2-DP2-SS)

All 316SS products meet the requirements of NACE MR0175/ISO 15156-3.

WARNING: This product can expose you to chemicals including Lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

WARNING: This product can expose you to chemicals including Nickel, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Differential Pressure to Static Plate

Used on gas pipelines, the Differential Pressure to Static Adaptor Plate is used to mount a differential pressure transmitter and a static pressure transmitter to a five valve flange-flange manifold. They are available in Zinc-Nickel plated Steel, electropolished Stainless Steel. An integral mini style bleed valve is incorporated in the plate and a 1/4" NPT vent plug is provided. The mini style bleed valve is equipped with a FKM o-ring and PTFE back-up ring below the stem threads to protect against corrosion and galling. Stem threads are rolled for greater strength and ease of operation and all NOSHOK valves are 100% helium leak tested for guaranteed reliability. Maximum pressure rating of 10,000 psi for Steel & Stainless Steel models.

  • ΔP to Static Adaptor, Steel (DP1-SA1-CS)
  • ΔP to Static Adaptor, Stainless Steel (DP1-SA1-SS)

All 316SS products meet the requirements of NACE MR0175/ISO 15156-3.

WARNING: This product can expose you to chemicals including Lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

WARNING: This product can expose you to chemicals including Nickel, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Direct Connect Assembly For Oil & Gas Applications

The NOSHOK Direct Connect Assembly provides an installation that keeps the meter close to the orifice taps for accurate flow measurements.

View the NOSHOK Direct Connect Assembly

Flare Pattern™ Valve Configuration

The Flare Pattern™ valve configuration (FP) is an available option on NOSHOK 5030/5130 and 5530 Series 5-valve natural gas manifold valves. The equalization valves and vent valve on these manifolds are angled to provide maximum clearance for fingers during operation.

Futbols 50FA1 Series

Futbols (flange adapters) bolt to the process side of a flange-flange manifold to allow connection of process flange taps or process root valves. Futbols also allow flanges to be connected to threaded process piping while maintaining the ease of removal or repair of the manifold if maintenance is required. The futbols provide a 1/16" offset connection from the bolt holes to give connection centers of 2", 2-1/8" or 2-1/4".

Specifications:

  • Carbon Steel Futbol, Pair, Steel (50FA1-CS)
  • Stainless Steel Futbol, Pair, Stainless Steel (50FA1-SS)
  • Material: Zinc-Nickel plated Steel, 316 Stainless Steel
  • Connections: 1/2" NPT
  • Kit Includes: (2) Futbols, (4) hex bolts 7/16"-20, (2) PTFE face seals
  • Weight approximately 2.1 lb.

All 316SS products meet the requirements of NACE MR0175/ISO 15156-3.

WARNING: This product can expose you to chemicals including Lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

WARNING: This product can expose you to chemicals including Nickel, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Manifold Mounting Kits - 3510 Manifolds & 5000 Series Manifolds

The manifold mounting kit is designed for direct or remote mounting to a two-inch pipe stand. This kit can be used with any NOSHOK 2-valve or 3-valve manifold by mounting a Steel or Stainless Steel bracket directly to the manifold body.

  • Flange - Flange Mounting Kit, Steel (MK3-CS1)
  • Flange - Flange Mounting Kit, 304 Stainless Steel (MK3-SS2)
  • Flange – NPT Mounting Kit, Steel (MK4-CS1)
  • Flange – NPT Mounting Kit, 304 Stainless Steel (MK4-SS2)
  • NPT – NPT Mounting Kit, Steel (MK4-SS2)
  • NPT – NPT Mounting Kit, 304 Stainless Steel (MK4-SS2)

3510 Series and 5-Valve Manifold Mounting Kit

O-Ring Options

  • Aflas (AF1)*
  • Kalrez 3018 (KZ1)*
  • Kalrez 4079 (KZ2)*
  • Simriz 89D (KZ3)*
  • Kalrez 7075 (KZ4)*
  • Elast O Lion (EL1)*
  • EPDM 80 (EM1)*
  • EPDM 90 (EM2)*
  • EPDM 70 (EM3)*
  • NBR 70 (NB1)*
  • EPDM 70 (EM1)**
  • Kalrez 4079 (KZ2)**
  • Elast O Lion (EL1)**
  • Low Temperature FKM (VT1)*
  • Low Temperature FKM (VT2)**

* For 1/8" NPT to 1/2" NPT only
** For 3/4" NPT to 1-1/2" NPT only

Static Adaptors SA Series

The Static Adaptor is used to join threaded ports to a flange style connection. They are often used to join the NPT port of a static transmitter with a flange mounted connection on a Differential Pressure to Static Adaptor Plate.

  • Static Adaptor, 1/2” Female NPT, Steel (SAC-1)
  • Static Adaptor, 1/2” Female NPT, Stainless Steel (SAS-1)
  • Static Adaptor, 1/2” Male NPT, Steel (SAC-2)
  • Static Adaptor, 1/2” Male NPT, Stainless Steel (SAS-2)

Specifications:

  • Material: Zinc-Nickel plated Steel, 316 Stainless Steel
  • Connections: 1/2" NPT Male-flange, 1/2" NPT Female-flange
  • Other configurations available

All 316SS products meet the requirements of NACE MR0175/ISO 15156-3.

WARNING: This product can expose you to chemicals including Lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

WARNING: This product can expose you to chemicals including Nickel, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Vertical to Horizontal Adaptor Kit

The Vertical to Horizontal Adaptor Kit converts vertically mounted Stabilized Connectors to a horizontal position for mounting additional valves and instrumentation.

  • Vertical to Horizontal Adaptor Kit, Steel (VHC)
  • Vertical to Horizontal Adaptor Kit, Stainless Steel (VHS)

All 316SS products meet the requirements of NACE MR0175/ISO 15156-3.

WARNING: This product can expose you to chemicals including Nickel, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Warranty Information - Accessories

WARNING:This product can expose you to chemicals including Lead and Nickel, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Valves

Frequently Asked Questions

A: The choice between alternative o-ring elastomers is based on specific application parameters that primarily include chemical compatibility and temperatures. For example, FKM may be used on higher temperature applications, or applications that require a broader range of chemical resistance than EPDM.

A: FKM (Viton Æ), PTFE (Teflon Æ) and Grafoil Æ are selected depending on the customer application. The customer will often designate what material is required for their application. This usually involves process parameters such as media, pressure, temperature and chemical compatibility. NOSHOK would not recommend any one material, but would be available to assist in the selection process.

A: A regulating stem is typically a tapered stem for metering and flow control applications. Stem tips are often used for solid shut-off where high repetitions of opening and closing of the valve occur.

A: A one piece valve stem rotates and translates along its axis as it is being driven axially into the orifice. The rotational motion of the stem produces an undesirable amount of friction and galling against the sealing surface if not properly lubricated. A non-rotating stem tip rotates independently from the stem and stops rotating as it is driven axially against the orifice sealing surface while the stem continues its rotational and axial movement. A ball tip is a type of non-rotating tip that is used when metering and flow control is not required and a quick opening and closing of the orifice is needed. Ball tips require a few turns to fully open and close the orifice. The spherical surface of ball tips have the advantage of easily sealing an orifice that may be slightly misaligned because multiple tangential contacts available on its surface. Material selection is primarily based on wear life. Regulating hard tip stems have increased metering capabilities. The stem incorporates a fine pitched thread that requires additional turns to open and a specially design stem tip taper that allows for a slow and gradual opening of the orifice. This feature is often used on high pressure gases that may freeze upon expansion if the pressure drops too quickly.

A: The choice between soft seat plastics, like o-ring elastomers, is application specific. Each plastic has its particular strengths depending on its wear resistance, chemical compatibility and heat resistance. DelrinÆ is a mid-range material with superior wear resistance and moderate heat and chemical resistance. PTCFE and PEEK are further up the performance range, but each increase in the range of properties has an associated increase in cost.

A: Utilization of the 2070, 2170 and 3070 Series is a matter of customer preference. The extended series offers a longer version for applications where more clearance may be needed in an installation. The operation of a standard length and extended length valve are identical.

A: Frequently, customers specify a redundant isolation block valve for safety in critical applications. A double block and bleed configuration provides two isolation valves with a bleed in between to enhance isolation and safety.

A: Dielectric Kits are designed to maintain the integrity and reliability of the pipeline and piping system through safety and corrosion protection. Dielectric Kits provide a non-conductive barrier between the process piping and the instrument and isolate components from the effects of electrical current. By eliminating metal-to-metal contact, current is halted to prevent corrosion and aid in the cathodic protection of the system. NOSHOK offers a single piece design Dielectric Kit and a two-piece design consisting of a PTFE sealing gasket and PVC dielectric shim for when a separate sealing gasket or o-ring is required.

A: Stabilized Connectors are designed to reinforce the entire installation by shifting radial-stress load away from the NPT connections. These connectors are offered with an optional integral block valve, eliminating the potential of pressure shock to the measurement device. The NOSHOK stabilized connector with integral valve can be installed on either side of the stabilized body, allowing easy half-turn installation for a level mounting surface and eliminating potential leak paths.

A: Futbols, or flange adapters, bolt to the process side of a flange-flange manifold to allow connection of process flange taps or process root valves. Futbols also allow flanges to be connected to threaded process piping while maintaining the ease of removal or repair of the manifold if maintenance is required. The Futbols provide a 1/16 inch offset connection from the bolt holes to give connection centers of 2 inches, 2-1/8 inches or 2-1/4 inches.

A: Compression packing is a soft, pliant and resilient rope material, braided with various filaments or yarns, configured for inserting into a mechanical device such as a valve. A PTFE stem seal provides a seal between the shaft of the handle stem and the valve body. This seal is then compressed around the stem by means of a packing gland, which forms a watertight seal around the handle stem assembly. When used with compatible fluids, valves utilizing packing have a much higher pressure versus temperature rating.

A: Block and bleed valves are traditional isolation valves, consisting of block and bleed (vent) needle valves to isolate and vent downstream pressure. Block and bleed valves are used to keep a system pressurized with a fluid or gas while venting pressure only from the process side.

A: Soft seat valves use a thermoplastic material such as PTFE or NBR, while hard seat valves use materials such as 316 stainless steel or Monel. The key advantage of hard seat valves over soft seat valves is that they can withstand high temperatures and harsh service conditions. In general applications, soft seat valves are suitable for use with clean fluids or gases and are not recommended for use with dirty or viscous fluids, as particulates may damage the soft seat material and cause leakage. If tight shut-off or bubble tight shut-off is required, a soft seat valve will provide superior sealing and shut-off capability in clean fluid applications. Hard seat valves can withstand extreme flashing, hydraulic shock, abrasive process fluid and ultra-high temperatures. In contaminated, erosive or corrosive fluid applications, a hard seat valve will provide better performance.
