- Continuous level measurement in containers and tanks
- Suitable for liquid, highly viscous and solid media
- Compact design for easy integration
- Can be installed outside a container (plastic)
- Suitable for industrial applications and mobile working machines
If you are viewing on a smaller screen or with screen zoom, please use
the horizontal scroll bar at the bottom of this table to see all information.
| SERIES |
LTI20 |
|
|
|
| OUTPUT SIGNALS |
36 |
4 mA to 20 mA, 3-wire |
2 |
0 Vdc to 5 Vdc, 3-wire |
| PROCESS CONNECTIONS |
8 |
1/2" NPT |
86 |
G1/2 (DIN 3852-2-A) |
| ELECTRICAL CONNECTIONS |
25 |
M12 x 1 (4-pin) |
36 |
6' integral cable |
| OPTIONS |
HT |
High Temp (302 °F [150 °C] Media Temp) |
If you are viewing on a smaller screen or with screen zoom, please use
the horizontal scroll bar at the bottom of this table to see all information.
| SPECIFICATIONS |
| Output signals |
4 mA to 20 mA, 3-wire
0 Vdc to 5 Vdc, 3-wire |
| Media dielectric constant |
≥2 |
| Measurement frequency |
FMCW (60 GHz technology); frequency band 57.4 ... 61.4 GHz |
| Min measuring distance |
4 in |
| Max measuring distance |
197 in [16 ft] (additional distances available, consult factory) |
| Beam angle |
±6° |
Measuring frequency
Settling time
Switch-on time |
> 1 Hz
1 s Per IEC 62828-1
<3 s |
| Accuracy parameters |
±0.2 inches Per IEC 62828-4 |
| Non-repeatability |
≤ 0.079 in |
| Response time |
4s |
| Temperature ranges |
| Media |
Standard |
-40 °F to 212 °F (-40 °C to 100 °C) |
| |
High Temp |
-40 °F to 302 °F (-40 °C to 150 °C) |
| Ambient |
|
-40 °F to 212 °F (-40 °C to 100 °C) |
| Storage: |
|
-40 °F to 158 °F (-40 °C to 70 °C) |
|
| Power requirement |
8 Vdc to 36 Vdc |
| Measuring element |
PEEK (Lens)
FKM (O-Ring) |
| Connection |
316L Stainless Steel |
| Housing material |
316L Stainless Steel |
| M12 electrical connection |
Nickle-plated Brass, Nylon |
| Cable jacket material |
PVC (Others available upon request) |
| Environmental rating |
IP67 |
| Electromagnetic rating |
RFI, EMI and ESD protection |
| Electrical protection |
Protected against reverse polarity, over-voltage and short circuit |
| Shock |
100g, 11 ms per IEC 60068-2-27 |
| Vibration (Short duration) |
40 g's, 10 to 2,000 Hz per IEC 60068-2-6 |
| Vibration (Long term) |
10 g's, 10 to 2,000 Hz per IEC 60068-2-6 |
| Max. operating pressure |
362 psi (25 bar) |
| Weight |
Approximately 2.8 oz. |
